Feature: Mixer Type: 6-channel Digital Signal Processor (DSP): Yes Bluetooth Function: Yes USB Input with MP3 Playback: Yes USB Recording Function: No Aluminium Side Panel: No Built-in Flight Case: No Built-in Layer Servo Fan: Single Layer Rack Mounted: No Specification: Output Power: 2 x 150 Watts (4Ω) Digital Signal Processor (DSP): 16 DSP alternative selector Balanced Mono Mic / Line Channel: 6 balanced mono mic / line channel TAPE / AUX Input: N/A Channels Section: Trim, High, Low, Effect, Pan Inserts: N/A Ultra-Musical Band EQ Channel: Ultra-musical 2-band EQ channel on all mono channel, 2-band with swept mid-range EQ Frequency Control on Mono Channel: N/A 80Hz High Pass Filter: Yes, to eliminate stage rumbling Peak LED Indicator: Yes, for all mono channel 48V Phantom Power: Yes, for ultra-low noise discrete mic preamps with 48V phantom power Segment Bargraph Meters: 5 segment bar-graph meters for main L/R output Volume Control: 45mm fidelity fader Stereo Graphic Equalizer: 1 x 5 band graphic EQ Monitor Out: N/A Phone Jack: 1 1/4″ phone jack output Phone & Monitor Level Control: Single volume control Master Output: 1 channel master output (L/R) with XLR and 1/4″ mono jack output Group Output: No AUX Send & AUX Return: 1-AUX send and 1-AUX return Record Out: 1-REC out (L/R) jack to deliver the main program signal to external recorder Speaker Output: 2-speaker output (L/R) with speakon connector and 1/4″ mono jack output Frequency Response: 22Hz-15kHz Product Dimension ( WxHxD ): 340mm x 130mm x 320mm Weight: 9.5kg
